Product Description

Food frying machine

1. Description

automatic food frying machine utomatic elevating system, automatic de-oil system, automatic conveying and cooling system and can finish fry, mix, de-oil and convey automatically.

Fryer can use electricity, gas, diesel as power source and can be widely used to fry the snacks, pellets, potato chips, sticks, beans, nuts, peanuts etc.

Compact structure of fryer, elevate, de-oil, convey, cooling function;Adopt PLC control achieve totally automatic working;Imported gas, diesel burner guarantee best power consumption with higher efficiency;Manuals and automatic control way, operation flexible

2. Technical Parameters:

model	heating temperature	output	size	(gas/diesel)consumption
LTF-B	Max.250	100-200kg/h	4600*2000*2000mm	45kw/h
LTF-BG	Max.250	100-200kg/h	4600*2000*2000mm	4.8-10m³/h(gas)    5.1-10kg/h(diesel)

3. Capacity: 100-200kg/h

4. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries

5. Machines materials: All the machines are made by stainless steel,

6. Sample pictures







7. Production

a.) Design: All the machines are elaborately designed by our mechanical engineers who are rich of experience in this field. We accept special design according to customer’s request.

b.) Processing & Assembling: Parts processing, assembly, testing are based on standard test.

c.) Trial Run: Each machine has to be tested before its deliver.



8. Delivery

The machines is possible to pack in wooden case or nude pack after wrapped by plastic film.
