Corn flakes ( breakfast cereals) processing line

Corn flakes ( breakfast cereals) processing line

Model No.︰LT65

Brand Name︰arrow

Country of Origin︰China

Unit Price︰US $ 80000 / pc

Minimum Order︰1 pc

Inquire Now

Product Description

Corn flakes ( breakfast cereals) processing line



1. twin screw extruder
2. Flakes, cereals, snacks
3. Corn flour as raw material

Corn flakes ( breakfast cereals) processing line

1. Description:

Corn flakes ( breakfast cereals) processing line  use corn and other cereals as main material, through mixing, extruding (or boiling), planishing, drying, baking, coating and coating and cooling, to get crispy flakes. It can be mixed with coffee or milk, or eaten as snacks.



2. Raw materials: adopts corn flour as raw materials



3. Products: Corn flakes ( breakfast cereals) processing line  can be used to produce snacks, cereals by adjusting the moulds from extruder



4. Capacity: 150kg/h, 260kg/h



5. Flow chart:

Mixing system---Extrusion system----Cooling system—Flaking system--Drying system—Toasted system---Sugar Spraying system ---Drying system---- Packing system



6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries



7. Machines Materials: All the machines are made by stainless steel



8. Technical Parameter:

Model

Installed power

Real power

Output

Dimension

LT65L

140kw

90kw

150kg/h

39000x1200x2200mm

LT70L

160kw

120kw

200kg/h

41000x1500x2200mm

LT85

190kw

140kw

300kg/h

43000x3500x4300mm



9.Brief Introduction of Corn Flake Making Machine



    Corn flakes is a kind of breakfast with high nutritional value. They usually use corn powder and other cereals as main material. Through mixing, extruding, drying, baking, coating and cooling to get crispy flakes. It always service as breakfast  cereal mixed with milk or coffee. but it can also be a kind of leisure  snacks.this process line can also make other shapes of cereal such as balls, chocos, curls etc.







10. Why We Are The Best Choice







1. Alloy (38CrMoAL) screw made by nitriding process, high strength and wear-resting.  Self-cleaning ability, no need to discharge or clean the barrel and screw when roasting or replacing of materials.

2. Adopting speed-adjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin screw feeding machine, stable materials feeding in the whole food process.

3. Gearbox with automatic lubrication function, extending gear life.

4. Increased radiator on driving part for forced cooling effect, ensuring extruder operates safely.

5. Barrel with water-cooled circulation, Different moisture-extrusion temperature ratio, whole-expanded and half expanded as different type of products.

6. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.


11. Corn flakes Snacks Sample Pictures



12.Strong Fumigation-Free Case or 20'GP or 40'HQ

Packed by wooden case or wrapped by plastic film then shipped by container.

13.Strong fumigation free case or 20GP or 40HQ

The machines is possible to pack in wooden case or nude pack after wraping by plastic film.



14.Service & Turnkey Solution

1.) Consultation service before, during,and after sales;

2.) Project planning and design service;

3.) Debugging of equipment until everything is functional;

4.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;

5.) Training of equipment maintenance and operating personally;

6.) New production techniques and formulas;

7.) Provide 1 year complete warranty and life-time maintenance service.

15. Company Information


16. Glories of Company


17. World Market
