Pellet food machine



1.Description

This processing line is for pellet and chips producing by single-screw extruder. The raw material can be potato starch, corn starch, cassava starch, wheat flour, etc. Through extruding cooking, the pellet can be different shapes like shell, spiral, square tube, circle tube, and so on. After drying the pellet need frying to get expanded.



2.Raw material:corn flour,wheat flour and other grain flour



3.Work flow chart



Flour Mixer---Screw Conveyer---Double-screw Extruer---Drawing and Cutting Machine---Cooling Machine---Drying Machine---Automatic Fryer---Flavoring Machine

4.Machine details



1) Alloy (38CrMoAL) screw made by nitriding process, high strength and wear-resting. Self-cleaning ability, no need to discharge or clean the barrel and screw when roasting or replacing of materials.

2)Adopting speedadjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin screw feeding machine, stable materials feeding in the whole food process.

3)Gearbox with automatic lubrication function, extending gear life.

4) World famous brand Siemens main motor, guaranteeing good quality

5)Increased radiator on driving part for forced cooling effect, ensuring extruder operates safely.

6)Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.



4.Sample show



5.Technical parameters of double-screw extrude machine



Model

Installed Power

main motor Power

Output

Size

LT65

34kw

22kw

120-150kg/h

2550x900x1850mm

LT65L

47kw

30kw

180kg/h

3500x950x1850mm

LT70

53kw

37kw

200-250kg/h

3200x760x2000mm

LT70L

54kw

37kw

200-250kg/h

3200x760x2000mm

LT85

99kw

75kw

500-700kg/h

3800 x1100x2350mm

LT85A

101kw

90kw

800-1000kg/h

3800 x1100x2350mm



6.Strong fumigation free case or 20’GP or 40’HQ

The machines is possible to pack in wooden case or nude pack after wraping by plastic film.



7.We provide satisfied service & turnkey solution



a.) Consultation service before, during, and after sales;

b.) Project planning and design service;

c.) Debugging of equipment until everything is functional;

d.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;

e.) Training of equipment maintenance and operating personally;

f.) New production techniques and formulas;

g.) Provide 1 year complete warranty and life-time maintenance service.



8.Who we are

We, Jinan Arrow Machinery Co., Ltd.are located in the famous industry city-Jinan city, capital of Shandong Province.



9.Our Prestigious Reputation Got from the World



Our machines are exported to more than 90 countries and areas and got high praise of customers. Some of them have become our agents in their area. We hope to hold long friendly business relationship with more clients all over the world in the future.





10.We are Reliable and Certified



Since the establishment of our company, we have always manufacturing our machines according to the authorized standards, by now ,we have got several certificates including CE and ISO9001 and we are 4 Years Alibaba Golden Supplier.
